WS-20Operation Voltage： 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)
Output Power ：15W
S.P.L. (at 100cm) ：110 ± 5 dB (at 12V DC)
Coil Impedance ：6 Ohm
Max.Rated Current ：600mA
Tone ：One tone/Six tone
Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)
Storage Temperature： -30℃ Min. to 70℃ Max.
Housing Material (A.B.S.) ：U/L recognized 105℃ (U/L 94HB)
-
WS-21Operation Voltage： 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)
Output Power ：15W
S.P.L. (at 100cm) ：110 ± 5 dB (at 12V DC)
Coil Impedance ：6 Ohm
Max.Rated Current ：600mA
Tone ：One tone/Six tone
Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)
Storage Temperature： -30℃ Min. to 70℃ Max.
Housing Material (A.B.S.) ：U/L recognized 105℃ (U/L 94HB)
-
WS-22Operation Voltage： 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)
Output Power ：15W
S.P.L. (at 100cm) ：110 ± 5 dB (at 12V DC)
Coil Impedance ：6 Ohm
Max.Rated Current ：600mA
Tone ：One tone/Six tone
Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)
Storage Temperature： -30℃ Min. to 70℃ Max.
Housing Material (A.B.S.) ：U/L recognized 105℃ (U/L 94HB)
-
WS-23Operation Voltage : 12V DC (Nominal )，6V DC (Min) – 15V DC (Max.)
Operation Current (at 12V DC) : 600mA (Typical.) , 1000mA (Max)
S.P.L.: (at 30cm) 110 ± 5 dB (at 12V DC)
Impedence: 6Ω
Tone :One tone/Six tone
Waterproof :IP57
Operation Temperature :-10℃ Min. to 85℃ Max. (10 minutes)
Storage Temperature : -40℃ Min. to 125℃ Max.
Housing Material :(PA) PA66&glass fibre
-
WS-24Operation Voltage： 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)
Output Power ：15W
S.P.L. (at 100cm) ：110 ± 5 dB (at 12V DC)
Coil Impedance ：6 Ohm
Max.Rated Current ：600mA
Tone ：One tone/Six tone
Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)
Storage Temperature ： -30℃ Min. to 70℃ Max.
Housing Material (A.B.S.) ：U/L recognized 105℃ (U/L 94HB)
-
WS-26Operation Voltage ：12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)
Output Power ：15W
S.P.L. (at 100cm)： 110 ± 5 dB (at 12V DC)
Coil Impedance： 6 Ohm
Max.Rated Current ：600mA
Tone ：One tone/Six tone
Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)
Storage Temperature ：-30℃ Min. to 70℃ Max.
Housing Material (A.B.S.) ：U/L recognized 105℃ (U/L 94HB)
-
WS-28Operation Voltage ：12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)
Output Power ：15W
S.P.L. (at 100cm)： 110 ± 5 dB (at 12V DC)
Coil Impedance： 6 Ohm
Max.Rated Current ：600mA
Tone ：One tone/Six tone
Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)
Storage Temperature ：-30℃ Min. to 70℃ Max.
Housing Material (A.B.S.) ：U/L recognized 105℃ (U/L 94HB)
-
WS-29Operation Voltage ：12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)
Output Power ：15W
S.P.L. (at 100cm)： 110 ± 5 dB (at 12V DC)
Coil Impedance： 6 Ohm
Max.Rated Current ：600mA
Tone ：One tone/Six tone
Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)
Storage Temperature ：-30℃ Min. to 70℃ Max.
Housing Material (A.B.S.) ：U/L recognized 105℃ (U/L 94HB)
