WS-50 Rated Voltage:DC 12V/24V
Operating Voltage:DC 6-15V/18-28V
SPL :118dB/m
Siren Tone :3 tones
Frequency :0.5~3K Hz
Tamper Switch: N.C.
Multifunction LED :Yes
Battery: DC12V,1.3AH(optional)

SC-06

Operation Voltage 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)

Power 20W

S.P.L. (at one meter) 110 ± 3 dB (at 12V DC)

Terminal block Siren/Horn/Strobe/Tamper/Spare

Flash frequency 60-80times/mintue

Tone One tone/Six tone

Operation Temperature -10℃ Min. to 60℃ Max. (10 minutes)

Storage Temperature -40℃ Min. to 80℃ Max.

Housing Material (A.B.S.) U/L recognized 105℃ (U/L 94HB)

SC-03

Operation Voltage 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)

Power 20W

S.P.L. (at one meter) 110 ± 3 dB (at 12V DC)

Terminal block Siren/Horn/Strobe/Tamper/Spare

Flash frequency 60-80times/mintue

Tone One tone/Six tone

Operation Temperature -10℃ Min. to 60℃ Max. (10 minutes)

Storage Temperature -40℃ Min. to 80℃ Max.

Housing Material (A.B.S.) U/L recognized 105℃ (U/L 94HB)

WP-18

Operation Voltage： 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)

Operation Current (at 12V DC) ： Siren:550mA(double piezo elements)

Strobe:120mA(XENON)/50mA(Led)

S.P.L. (at 100cm) ：112 ± 5 dB (at 12V DC)

FLASH： 80times/minute

Operation Frequency： 1.5KHz -3.5 KHz

Tone： warble

Operation Temperature ：-20℃ Min. to 60℃ Max. (10 minutes)

Storage Temperature ：-30℃ Min. to 70℃ Max.

WP-13

Operation Voltage: 12V DC (Nominal )，6V DC (Min) – 15V DC (Max.)

Operation Current (at 12V DC) : 130mA (Typical.) , 170mA (Max)

S.P.L. (at one meter) :110 ± 3 dB (at 12V DC)

Flash frequency: 60-80times/mintue

Tone: Buzzer(can be customized)

Operation Temperature: -10℃ Min. to 60℃ Max. (10 minutes)

Storage Temperature :-40℃ Min. to 80℃ Max.

Housing Material (A.B.S.) :U/L recognized 105℃ (U/L 94HB)

Remark: Lens color RED/BLUE/ORANGE

WP-12

Operation Voltage: 12V DC (Nominal )，6V DC (Min) – 15V DC (Max.)

Operation Current (at 12V DC): 130mA (Typical.) , 170mA (Max)

S.P.L. (at one meter): 105 ± 3 dB (at 12V DC)

Flash frequency:* 60-80times/mintue

Tone: Buzzer(can be customized)

Operation Temperature: -20℃ Min. to 60℃ Max.

Storage Temperature: -40℃ Min. to 80℃ Max.

Housing Material (A.B.S.): U/L recognized 105℃ (U/L 94HB)

Remark: Lens color RED/BLUE/ORANGE

WP-12

Operation Voltage: 12V DC (Nominal )，6V DC (Min) – 15V DC (Max.)

Operation Current (at 12V DC): 130mA (Typical.) , 170mA (Max)

S.P.L. (at one meter): 105 ± 3 dB (at 12V DC)

Flash frequency:* 60-80times/mintue

Tone: Buzzer(can be customized)

Operation Temperature: -20℃ Min. to 60℃ Max.

Storage Temperature: -40℃ Min. to 80℃ Max.

Housing Material (A.B.S.): U/L recognized 105℃ (U/L 94HB)

Remark: Lens color RED/BLUE/ORANGE

WP-06

Operation Voltage ：12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)

Operation Current (at 12V DC) ： Siren:200mA  Strobe:120mA(XENON)/50mA(Led)

S.P.L. (at 100cm)： 105 ± 5 dB (at 12V DC)

FLASH： 80times/minute

Operation Frequency ：1.5KHz -3.5 KHz

Tone： HI-LO

Operation Temperature ：-20℃ Min. to 60℃ Max.

Storage Temperature： -30℃ Min. to 70℃ Max.

Housing Material (A.B.S.)： U/L recognized 105℃ (U/L 94HB)
