WP-02

Operation Voltage: 12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)

Operation Current(at 12V DC) :160mA (Typical.) , 250mA (Max)

S.P.L. (at 100cm) :105 ± 5 dB (at 12V DC)

Operation Frequency: 1.5KHz -3.5 KHz

Tone: Warble & Hi-Low

Operation Temperature: -20℃ Min. to 70℃ Max. (10 minutes)

Storage Temperature: -30℃ Min. to 80℃ Max.

Housing Material: (A.B.S.) U/L recognized 105℃ (U/L 94HB)

WP-01

Operation Voltage:12V DC (Nominal )，9V DC (Min) – 15V DC (Max.)

Operation Current(at 12V DC) :130mA (Typical.) , 200mA (Max)

S.P.L.(at 100cm):105 ± 5 dB (at 12V DC)

Operation Frequency:1.5KHz -3.5 KHz

Tone:Warble & Hi-Low

Operation Temperature:-20℃ Min. to 70℃ Max. (10 minutes)

Storage Temperature:-30℃ Min. to 80℃ Max.

Housing Material(A.B.S.):U/L recognized 105℃ (U/L 94HB)
